万能切管机

特性

  • 适合切大管径铸铁,陶土,水泥,钢,PVC及PE管。
  • 一台主机,选择不同的刀片,则可切各种管子。

当地购买

Online Video Training Truck Freight Required
品名订货号管直径 应用 毛重 [1]
公称尺寸 实际外直径毫米 千克
UPC636A 075106 - 36 150 - 1000 Cast/Ductile Iron, Clay, Concrete, CPVC, PE, PVC Sch. 40, PVC C900 & C905, Steel Sch. 40 131 59.5
UPC648A 075116 - 48 150 - 1300 Cast/Ductile Iron, Clay, Concrete, CPVC, PE, PVC Sch. 40, PVC C900 & C905, Steel Sch. 40 138 62.7
UPC616A 075126 - 16 150 - 450 Cast/Ductile Iron, Clay, Concrete, CPVC, PE, PVC Sch. 40, PVC C900 & C905, Steel Sch. 40 89 40.5
UPC616AP [2]075136 - 16 150 - 450 PVC Sch. 40, C900/C905, CPVC 75 34.1
UPC836APE [3]075178 - 36 200 - 1000 PE, HDPE 101 45.9
UPC848APE [3]075188 - 48 200 - 1300 PE, HDPE 106 48.2
[1]

最重的切割器部件仅有 28 磅/13 千克。重量包括所有物件和钢工具箱。

[2]

最新!

[3]

Exclusive

Must order REQUIRED blades SEPARATELY.

UPC836APE, UPC848APE come with two blades.

Why Reed

力得万能切管机轻便、快速,管子周 围只需12寸操作空间。切割笔直。 可以在水下作业。是目前市场上最安 全、简易和快速的动力切管机。安 装、操作和维护都很方便,因此总体 成本低。

这些轻便、易用的万能切管机适合切割6到48寸的球墨铸铁、铸铁、陶土、 水泥、碳钢、PVC或PE管。切管机为气动。成本低的UPC616A和其他款采用 的发动机型号是一样的,但不包括切大管时所需的连接架。UPC616A由钢 制工具箱包装,同时配有三加仑铸钢水桶。UPC636A和UPC648A由钢制工 具箱包装,配有6加仑不锈钢水桶和小车。所有万能切管机都配有空气过滤 调节和润滑装置。



UPC836APE and UPC848APE are designed specifically for cutting PE pipe. The kit includes a 6" and 8" carbide tipped blade. The 8" blade will cut large diameter PE pipe with a wall thickness up to 2.65" (67mm). UPC836APE and UPC848APE also come in a steel box but without the water tank.



Standard Equipment

Standard EquipmentUPC616AUPC636AUPC648AUPC836APEUPC848APE
Power Cutter with 1.7 H.P. Motor
Chain/Turnbuckle Assembly ✓cut up to 16"
Connection Frames & Chain to cut up to N/A 36" 48" 36" 48"
Filter/Regulator/Lubricator with Stand
Water Tank 3 gallon 6 gallon w/cart 6 gallon w/cart
Carrying Case
Air Motor Oil
Grease Gun
Hex Key Wrench Set
Open End Wrenches
Wedges
UPCSTEEL6 6” blade
UPCPE8 8” blade



Universal Pipe Cutter Power Requirements

Maximum R.P.M. 3675
Air Consumption 50 cu. ft./min (1.4 cu. m/min.)
Pressure  90 P.S.I. Maximum (6 BAR)
Shut-Off 3/4" Ball Valve
Air Supply Fittings 3/4" Dixon "Air King" Coupling



万能切管机的发动机可以寄回厂家修理。客户需预先支付运费,工具到 达工厂后公司会针对修理费用给予报价。

全集的 Reed 培训视频 可参见 “资源” 菜单。
